Single Center Leg

$64.00

*Image not available.

Please Note: This Model Is Non-Stock, Made To Order, Non-Refundable.

SKU
LEG
main product photo
Untitled Document
gsa logo

BALL TRANSFER TABLE
The Ball Transfer Table is used when products are
required to be manually rotated or correctly positioned,
such as a work station or other similar operation that
requires quick, easy handling of the product. Ball
Transfer Table is also used when more than two
conveyor lines converge and packages must be
transferred from one line to another.
ball transfer table
1 in. Ball Casters
Steel Channel Frame 3-1/2 in. x 1-1/2 in. x 10 ga.,
2-1/2 in. x 1 in. x 12 Ga. (Specify skate wheel or 138
Roller Type when mounted in 2-1/2 in. channel)
SEE BELOW FOR SUPPORTS
stationary floor supports
NOTE: Stationary Floor Supports (as shown in
photo) ARE NOT INCLUDED IN PRICE.
Solid Green prices indicate items available for 24-Hour Shipment.
Solid Black prices indicates items available for 2-week shipment.

Order Online

Click the button of the item you wish to purchase.

Contact us for special lengths

ball transfer
ball transfer
BALL TRANSFER
1" Dia. Ball, Stud Mount (019.101) ........... $6.11
ball transfer
PRICES FOR BALL TRANSFER TABLE INCLUDE:
1" Dia. Ball Casters 1" Dia. Ball Casters
3-1/2" x 1-1/2" x 10 Ga. powdered painted
channel frame		 2-1/2" x 1" x 12 Ga. powdered painted
channel frame

Pricing Note: Last number in model number is the ball center dimensions.
Example: BTT25-10-3 have balls on 3" centers
PRICING FOR 3-1/2" FRAME
BALL TRANSFER TABLE
PRICING FOR 2-1/2" FRAME
BALL TRANSFER TABLE
Over
All
Width		 Between
Rail
Width		 Conveyor
Model No.		 Price
Per Foot
16" 13" BTT 35-13-2
$220.22
16" 13" BTT 35-13-3
$111.78
16" 13" BTT 35-13-4
$67.71
16" 13" BTT 35-13-6
N/A
18" 15" BTT 35-15-2
$254.75
18" 15" BTT 35-15-3
$128.43
18" 15" BTT 35-15-4
$77.81
18" 15" BTT 35-15-6
N/A
20" 17" BTT 35-17-2
$289.27
20" 17" BTT 35-17-3
$145.19
20" 17" BTT 35-17-4
$87.91
20" 17" BTT 35-17-6
$53.06
22" 19" BTT 35-19-2
$323.68
22" 19" BTT 35-19-3
$161.95
22" 19" BTT 35-19-4
$98.01
22" 19" BTT 35-19-6
$61.27
24" 21" BTT 35-21-2
$358.20
24" 21" BTT 35-21-3
$178.60
24" 21" BTT 35-21-4
$108.11
24" 21" BTT 35-21-6
$69.38
26" 23" BTT 35-23-2
$392.61
26" 23" BTT 35-23-3
$195.36
26" 23" BTT 35-23-4
$118.33
26" 23" BTT 35-23-6
$77.59
28" 25" BTT 35-25-2
$427.13
28" 25" BTT 35-25-3
$212.01
28" 25" BTT 35-25-4
$128.43
28" 25" BTT 35-25-6
$85.69
30" 27" BTT 35-27-2
$461.54
30" 27" BTT 35-27-3
$228.66
30" 27" BTT 35-27-4
$138.53
30" 27" BTT 35-27-6
$93.80
34" 31" BTT 35-31-2
$530.58
34" 31" BTT 35-31-3
$262.18
34" 31" BTT 35-31-4
$158.84
34" 31" BTT 35-31-6
$110.22
36" 33" BTT 35-33-2
$564.99
36" 33" BTT 35-33-3
$278.94
36" 33" BTT 35-33-4
$168.83
36" 33" BTT 35-33-6
$118.44
40" 37" BTT 35-37-2
$633.92
40" 37" BTT 35-37-3
$312.24
40" 37" BTT 35-37-4
$189.14
40" 37" BTT 35-37-6
$134.64
42" 39" BTT-35-39-2
$668.44
42" 39" BTT-35-39-3
$329.00
42" 39" BTT-35-39-4
$199.36
42" 39" BTT-35-39-6
$142.75
Over
All
Width		 Between
Rail
Width		 Conveyor
Model No.		 Price
Per Foot
12" 10" BTT 25-10-2 $183.93
12" 10" BTT 25-10-3 $91.80
12" 10" BTT 25-10-4 $57.05
12" 10" BTT 25-10-6 N/A
15" 13" BTT 25-13-2 $236.76
15" 13" BTT 25-13-3 $115.77
15" 13" BTT 25-13-4 $71.48
15" 13" BTT 25-13-6 N/A
18" 16" BTT 25-16-2 $289.49
18" 16" BTT 25-16-3 $139.75
18" 16" BTT 25-16-4 $85.91
18" 16" BTT 25-16-6 $50.73
24" 22" BTT 25-22-2 $395.05
24" 22" BTT 25-22-3 $187.81
24" 22" BTT 25-22-4 $114.89
24" 22" BTT 25-22-6 $72.26
IMPORTANT NOTES...
OTHER WIDTHS
Contact us for lead time.
NON-STANDARD WIDTHS
Contact us for lead time.
LOAD CAPACITY CHART
Frame
Size		 Support
Centers		 Frame Capacity (Lbs.)
Maximum Distributed
Live Load Per Foot		 Each Ball Caster
2-1/2" x 1" x 12 Ga. 5' 270
65
Lbs
(Skatewheel Frame) 10' 38

3-1/2" x 1-1/2" x 10 Ga.		 5' 620
10' 135
Less Frame ...........................................Deduct Per Foot ............................... $5.20
Ball Caster
Centers
BETWEEN RAIL WIDTHS (Weights Per Foot)
*10"
13"
15"
*16"
17"
19"
21"
*22"
23"
25"
27"
31"
33"
37"
39"
2"
19.77
25.86
29.15
29.60
32.45
35.72
39.28
41.77
42.27
45.52
48.81
55.35
58.65
65.19
68.48
3"
15.09
18.06
20.57
21.02
21.53
23.99
25.50
26.95
27.45
29.92
32.43
35.85
38.37
41.79
44.30
4"
12.75
15.33
17.45
17.90
18.41
20.48
21.43
21.80
23.55
24.46
26.58
29.61
30.57
33.60
35.72
6"
-
-
-
15.56
16.07
16.97
18.70
19.15
19.65
20.56
22.90
24.15
25.86
27.75
29.48
All weights are conveyor weights only. Accessories, crating, etc., are not included.
* Supplied in 2-1/2" in. x 1 in. x 12 Ga. frame only.

STATIONARY FLOOR SUPPORTS
stationary floor supports PRICES FOR STATIONARY SUPPORTS INCLUDE:
Welded Frame Assembly
Adjustable Feet
Adjustable Pivot Plate
Use "MS" supports with 3-1/2" channel frame and "LS" supports for
2-1/2" frames
Solid Green prices indicate items available for 24-Hour Shipment.
Solid Black prices with Brown shading indicate items available for 3-Day
Shipment.

Order Online

Click the button of the item you wish to purchase.

Contact us for special lengths

PRICING FOR "LS" SUPPORT FOR 2-1/2" CHANNEL
Model No. Adjustment to Top of Roller Weight
(Lbs.)		 Price Up to
60" Each		 Price Up Above
61" Each
Wheel & 1-3/8" Roller
LSL-1 4-13/16" to 5-13/16" 8 $40.96 $40.96
LSL-2 5-13/16" to 7-9/16" 8 $40.96 $40.96
LSL-3 7-9/16" to 10-3/16" 8 $40.96 $40.96
LS-1 10-1/16" to 11-13/16" 8 $40.96 $40.96
LS-1.2 11-1/16" to 12-13/16" 8 $40.96 $40.96
LS-1.4 12-1/16" to 13-13/16" 8 $40.96 $40.96
LS-2 13-1/16" to 16-1/16" 8-1/2 $42.29 $42.18
LS-3 15-11/16" to 18-11/16" 11 $46.51 $46.51
LS-4 18-11/16" to 24-11/16" 13-1/2 $53.61 $53.61
LS-5 22-11/16" to 28-11/16" 19-1/2 $55.94 $55.94
LS-6 26-11/16" to 38-11/16" 22-1/2 $61.72 $91.13
LS-7* 36-11/16" to 48-11/16" 24 $91.13 $115.66
LS-8* 48-11/16" to 60-11/16" 26-1/2 $104.12 $129.98
LS-9* 60-11/16" to 72-11/16" 29-1/2 $114.00 $143.97
LS-10* 72-11/16" to 84-11/16" 35-1/2 $129.98 $149.18
LS-11* 82-11/16" to 94-11/16" 38-1/2 $143.75 $152.85
LS-12* 94-11/16" to 106-11/16" 42 $150.41 $178.71
*Price Includes Knee Braces.

Order Online

Click the button of the item you wish to purchase.

Contact us for special lengths

PRICING FOR "MS" SUPPORT FOR 3-1/2" CHANNEL
Model No. Adjustment to Top of Roller Adjustment to Top of Roller Weight
(Lbs.)		 Price Up to
60" Each		 Price Up Above
61" Each
1.9" & 2" Roller 2514 Roller
MSL-1
5-3/4" to 6-3/4"
6-1/16" to 7-1/16"
8
MSL-2
6-3/4" to 8-1/2"
7-1/16" to 8-13/16"
8
MSL-3
8-1/2" to 11-1/8"
8-13/16" to 11-7/16"
8
MS-1
10-3/4" to 12-1/2"
11-1/16" to 12-13/16"
8
MS-1.2
11-3/4" to 13-1/2"
12-1/16" to 13-13/16"
8
MS-1.4
12-3/4" to 14-1/2"
13-1/16" to 14-13/16"
8
MS-2
13-3/4" to 16-3/4"
14-1/16" to 17-1/16"
8-1/2
MS-3
16-3/8" to 19-3/8"
16-11/16" to 19-11/16"
11
MS-4
19-3/8" to 25-3/8"
19-11/16" to 25-11/16"
13-1/2
MS-5
23-3/8" to 29-3/8"
23-11/16" to 29-11/16"
19-1/2
MS-6
27-3/8" to 39-3/8"
27-11/16" to 39-11/16"
22-1/2
MS-7*
37-3/8" to 49-3/8"
37-11/16" to 49-11/16"
24
MS-8*
49-3/8" to 61-3/8"
49-11/16" to 61-11/16"
26-1/2
MS-9*
61-3/8" to 73-3/8"
61-11/16" to 73-11/16"
29-1/2
MS-10*
73-3/8" to 85-3/8"
73-11/16" to 85-11/16"
35-1/2
MS-11*
83-3/8" to 95-3/8"
83-11/16" to 95-11/16"
38-1/2
MS-12*
95-3/8" to 107-3/8"
95-11/16" to 107-11/16"
42
*Price Includes Knee Braces.

Order Online

Click the button of the item you wish to purchase.

Contact us for special lengths

IMPORTANT NOTES.....
4 in. Dia. 6 in. Dia.
CASTERS Steel Rubber Steel Rubber
Extra Per Support*
CASTERS
Are available in either Rigid or Swivel type - specify.
WHEN ORDERING SUPPORTS
*Price Includes Knee Braces.
Specify Overall Conveyor Width.
CAPACITY DATA CASTERS ARE RECOMMENDED FOR MS AND
LS TYPE SUPPORTS ONLY.
LS & MS .......................... 1500 lbs. ea.
Caster Foot ..................Per Support ........... $37.07
Floor Lock ..........................Each.............. $128.87 (Customer supplied caster must match our caster bolt pattern)
Knee Braces ......................Per Pair ......... $20.31 *Available on Swivel Caster Only.
Single Center Leg..................................... $42.29** **Center legs available from stockyards, same sizes as
LS-MS shown in chart above.
Brakes for Casters (Add-On Per Support)*:
4" Dia. Caster ....................................... $26.64
6" Dia. Caster ....................................... $85.14
